--- title: Hand Roll Irrigation System | Easy Manual Operation | IRRILINE description: Hand Roll Irrigation System, a cost-effective & manual solution for irrigation, designed for easy operation by a single worker across various crop types. image: https://www.irriline.com/hubfs/side-roll-slide-5.jpg --- [![](https://www.irriline.com/hubfs/irriline_logo.png)](https://www.irriline.com) - [Home](https://www.irriline.com) - [Products](https://www.irriline.com/products) - [Pricing](https://www.irriline.com/pricing) - [Blog](https://www.irriline.com/blog) - [Resources](https://www.irriline.com/resources) - [About Us](https://www.irriline.com/about-us) [Contact Us](https://www.irriline.com/contact-us) # Hand Roll Irrigation System Manual irrigation made easy with the Hand Roll system. No power unit is needed; it can be effortlessly operated by a single worker with a double-wheel system fixed in the middle, providing a cost-effective and user-friendly solution. [Contact Us](https://www.irriline.com/contact-us) Learn More ![equip\_img](https://www.irriline.com/hubfs/equip_img.jpg) ## Dealers Who Have Trusted Us ![hmt-hydraulique-logo-white-bg](https://www.irriline.com/hubfs/hmt-hydraulique-logo-white-bg.jpg) ![champ-irri-services-white-bg](https://www.irriline.com/hubfs/champ-irri-services-white-bg.jpg) ![summerfield-white-bg](https://www.irriline.com/hubfs/summerfield-white-bg.jpg) ![lawn-white-bg](https://www.irriline.com/hubfs/lawn-white-bg.jpg) ![farma-white-bg](https://www.irriline.com/hubfs/farma-white-bg.jpg) ![cropglow-white-bg](https://www.irriline.com/hubfs/cropglow-white-bg.jpg) ## What is new in IRRILINE Hand Roll Irrigation Systems? - Overview - Features - Operation - Specification - Performance - Spare Parts Select Tab - Overview - Features - Operation - Specification - Performance - Spare Parts ## Hand Roll New Features **The Hand Roll Irrigation System** is similar to the Side Roll Irrigation System, but there is no power unit. It can operate manually by a single worker with double wheel fixed in the middle of the system. - **Hand Roll Pipe:** All Pipes used are 4”x 6M extruded Aluminum Pipes. - **Sprinkler:** 3/4” Full circle brass sprinklers mounted on leveler with 12M interval on the system. - **Wheels:** All wheels are made with hot-deep galvanized, fixed on the system with 12M interval. Two wheels, each fixed on both end of the system for better alignment. ![handroll](https://www.irriline.com/hubfs/handroll.png) - **Connection to Hydrant:** Hand Roll Irrigation System connects to Hydrant by 4” x 6M Flexible hose with 10 Bar Pressure and UV resistance. - **Length of the System:** Hand Roll Irrigation System is available from 72M to 192M. - **Covering Area:** Irrigating area covered by a Hand Roll Irrigation System depends on length of farm, soil and climate. Refer to data in the table below: ## IRRILINE Hand Roll Wheel’s is available in Different heights. - 158cm Wheels - 193Cm Wheels ![hand-roll-158cm](https://www.irriline.com/hubfs/hand-roll-158cm.png) ![hand-roll-193cm](https://www.irriline.com/hubfs/hand-roll-193cm.png) ## Covering Area Irrigating area covered by a Hand Roll Irrigation System is depends on length of farm, soil and climate. Refer to the data table below: | Hand Roll Length (M) | Farm Dimension (M) | Covering area (Hectare) | Irrigating time in each position | Irrigating position OR Movement per Day | | --- | --- | --- | --- | --- | | 72 | 81 X 400 | 3.30 | 4 to 5 Hours | 3 to 4 Times | | 84 | 93 x 400 | 3.80 | 4 to 5 Hours | 3 to 4 Times | | 96 | 107 x 400 | 3.30 | 4 to 5 Hours | 3 to 4 Times | | 108 | 119 x 400 | 3.30 | 4 to 5 Hours | 3 to 4 Times | | 120 | 131 x 400 | 3.30 | 4 to 5 Hours | 3 to 4 Times | | 132 | 143 x 400 | 3.30 | 4 to 5 Hours | 3 to 4 Times | | 144 | 155 x 400 | 3.30 | 4 to 5 Hours | 3 to 4 Times | | 156 | 167 x 400 | 3.30 | 4 to 5 Hours | 3 to 4 Times | | 168 | 179 x 400 | 3.30 | 4 to 5 Hours | 3 to 4 Times | | 180 | 191 x 400 | 3.30 | 4 to 5 Hours | 3 to 4 Times | | 192 | 199 x 400 | 3.30 | 4 to 5 Hours | 3 to 4 Times | Hand Roll Irrigation System: It is Side Roll without power unit, with max 156M length for small farms. It is easy to move by a single person without any difficulty. Hand Roll is useful for wheat, Barely, Alfa Alfa, Potato, Sugar-beet, Soybean, Grass etc. Hand Roll is connected to Hydrant by 4” x 6M Flexible Hose. The dimension of each pipe is 4” x 6M and it has one wheel with 193Cm diameter. In this case, the distance between ground and pipe will be 93Cm and sprinkler will be 110Cm high from the earth. The distance between 2 Sprinklers is 12M, and the movement will be 3 turn of the wheels, which is 18M. Each sprinkler is mounted on the pipe by leveller for keeping its vertical position. #### Sprinkler ![handroll\_features02](https://www.irriline.com/hubfs/handroll_features02.jpg) Each 6M Pipe has a sprinkler with Protection cap fixed with leveler to keep the position of the sprinklers vertical. #### Coupler ![](https://www.irriline.com/hubfs/2aced2ab3c6c5a7e59a719ab39df8f3c.jpg) Made of Die Cast Aluminum with Quick Connection. Easy to assemble and take down the line. #### Flexible Hose ![handroll\_features04](https://www.irriline.com/hubfs/handroll_features04.jpg) 4” x 6M UV Treated flexible hose is connected from middle or one end of the Hand Roll (depends on the length of the Hand Roll) to supply water from Hydrant to Machine. #### Stabilizer ![handroll\_features05](https://www.irriline.com/hubfs/handroll_features05.jpg) Strong stabilizer for windy climate and long term parking. #### End Plug ![handroll\_features06](https://www.irriline.com/hubfs/handroll_features06.jpg) Manual Valve for Cleaning the Line. #### Drain Valve ![handroll\_features07](https://www.irriline.com/hubfs/handroll_features07.jpg) Drain Valve is fixed on each female coupler to discharge the water automatically when the hydrant is closed. ##### Operations of Hand Roll Hand Roll is an aluminum pipe (lateral) mounted on large wheels. The Hand Roll irrigates in place (does not move while irrigating), and it is moved from position to position between irrigation runs. An air-cooled gasoline engine provides the required power to move the aluminum sprinkler line across the field. The aluminum pipe is connected to hydrants by a flexible hose. The hydrants are usually spaced every 18 meters (60′) along the supply line (mainline). The supply line may be located along one edge or in the center of the field.   The Hand Roll is very simple to operate. When an irrigation run is finished, the operator simply turns off the mainline valve and disconnects the flexible hose. The drain valves automatically drain the pipe due to the reduced pressure. The operator then manually moves the line and rolls the pipe to the next hydrant position along the field, reconnects the flexible hose, turns on the water and starts the next irrigation run. The whole operation of repositioning takes about 20 minutes for a single person. When the Motoroll has reached the last position at the end of the field, it is driven back to the starting point for the next irrigation cycle.         ![handroll1](https://www.irriline.com/hubfs/handroll1.gif) #### Pipe **A.** 100 mm x 12 m x 1.8 mm (4″ x 40′ x 0.071″) extruded aluminum pipe with male and female couplers. **B.** 100 mm x 12 m x 1.8 mm (4″ x 40′ x 0.071″) extruded aluminum pipe with male and female couplers. #### Hose Set 1. 100 mm x 6 m (4″ x 20′) UV-treated flexible discharge hose with standard adapters. 2. 100 mm x 100 mm (4″ x 4″) hydrant opener. #### Couplers 1. Quality die cast aluminum couplers, fixed with epoxy and handle band. 2. Female couplers with outlet and flapper. 3. Quality torque coupler clamp and gaskets. #### Sprinklers 1. Brass sprinklers with protection cap, 1.8 m3/hr flow rate and about 18 m radius with 4 bar operating pressure. 2. Galvanized sprinkler levelers, risers and elbows. #### Wheels Hot dip galvanized 1.47 m (58″), 1.93 m (76″), or 2.85 m (112″) diameter wheels, including 20 spokes, hubs, half rims, 10 strong 3 mm cleats. #### End Plug Die cast flush plug with splash guard for cleaning debris. #### Stabilizers Galvanized stabilizers for windy conditions (optional). ##### Performance of Side Roll Area (Ha) irrigated by a Side Roll: for different lengths, application rates, and irrigation cycles ![Frame 283](https://www.irriline.com/hs-fs/hubfs/Frame%20283.png?width=1440&height=644&name=Frame%20283.png) | Parts | Parts Number | Description | | --- | --- | --- | | ![i5](https://www.irriline.com/hs-fs/hubfs/i5.jpg?width=190&height=118&name=i5.jpg) | I-01-20-553/1 I-01-20-553/2 | Sprinkler 3/4″ FC Sprinkler 3/4″ PC | | ![i25](https://www.irriline.com/hs-fs/hubfs/i25.jpg?width=190&height=118&name=i25.jpg) | I-01-20-018 | Aluminum Half Torque Coupler (Male) | | ![i26](https://www.irriline.com/hs-fs/hubfs/i26.jpg?width=190&height=118&name=i26.jpg) | I-01-20-2504 | Aluminum Half Torque Coupler (Female) | | ![i27](https://www.irriline.com/hs-fs/hubfs/i27.jpg?width=190&height=118&name=i27.jpg) | I-01-20-314 | Drain Valve | | ![i28](https://www.irriline.com/hs-fs/hubfs/i28.jpg?width=190&height=118&name=i28.jpg) | I-01-20-314/1 | Rubber Flapper | | | I-01-20-700 | Stabilizer | | ![i29](https://www.irriline.com/hs-fs/hubfs/i29.jpg?width=190&height=118&name=i29.jpg) | I-01-20-339/1 | Complete Motoroll Hose | | ![i30](https://www.irriline.com/hs-fs/hubfs/i30.jpg?width=190&height=118&name=i30.jpg) | I-01-20-339/2 | Hose to Male End Adapter | | ![i30](https://www.irriline.com/hs-fs/hubfs/i30.jpg?width=190&height=118&name=i30.jpg) | I-01-20-339/3 | Standard Hose Clamp | | ![i32](https://www.irriline.com/hs-fs/hubfs/i32.jpg?width=190&height=118&name=i32.jpg) | I-01-20-339/4 | Galvanized Handle Band | | ![i33](https://www.irriline.com/hs-fs/hubfs/i33.jpg?width=190&height=118&name=i33.jpg) | I-01-20-540 I-01-20-540/1 | Flush out End Plug End Plug without Outlet | | ![i34](https://www.irriline.com/hs-fs/hubfs/i34.jpg?width=190&height=118&name=i34.jpg) | I-01-20-335 I-01-20-335/1 | Slip Joint Coupler S. J. C. with Outlet | | ![i35](https://www.irriline.com/hs-fs/hubfs/i35.jpg?width=190&height=118&name=i35.jpg) | I-01-20-337 | Hydraulic Flange Adapters | | ![i36](https://www.irriline.com/hs-fs/hubfs/i36.jpg?width=190&height=118&name=i36.jpg) | I-01-20-337/1 | Hydraulic Flange Adapters Gasket | | ![i](https://www.irriline.com/hs-fs/hubfs/i.jpg?width=190&height=118&name=i.jpg) | I-01-20-313 | Motoroll Complete Wheels | | ![i38](https://www.irriline.com/hs-fs/hubfs/i38.jpg?width=190&height=118&name=i38.jpg) | I-01-20-296 | Half Rims | | ![i39](https://www.irriline.com/hs-fs/hubfs/i39.jpg?width=190&height=118&name=i39.jpg) | I-01-20-550 | Motoroll Spokes | | ![i40](https://www.irriline.com/hs-fs/hubfs/i40.jpg?width=190&height=118&name=i40.jpg) | I-01-20-267 | Motoroll Cleat | | ![i41](https://www.irriline.com/hs-fs/hubfs/i41.jpg?width=190&height=118&name=i41.jpg) | I-01-20-250 I-01-20-251 I-01-20-250/1 I-01-20-250/2 I-01-20-251/1 | 4”X6 m Alum Pipe 4”X12 m Alum Pipe 4”X6 m Alum Pipe w/F&C without Outlet 4”X6 m Alum Pipe w/F&C with Outlet 4”X12 m Alum Pipe with 2 Coupler | | ![i42](https://www.irriline.com/hs-fs/hubfs/i42.jpg?width=190&height=118&name=i42.jpg) | I-01-20-277 | Motoroll Hub Half | | ![i43](https://www.irriline.com/hs-fs/hubfs/i43.jpg?width=190&height=118&name=i43.jpg) | I-01-0-505/2 | Torque Coupler Hold Band | | ![i44](https://www.irriline.com/hs-fs/hubfs/i44.jpg?width=190&height=118&name=i44.jpg) | I-01-20-505 | Torque Coupler Clamp | | ![i45](https://www.irriline.com/hs-fs/hubfs/i45.jpg?width=190&height=118&name=i45.jpg) | I-01-10-077 | ¾” Brass Valve | | ![i46](https://www.irriline.com/hs-fs/hubfs/i46.jpg?width=190&height=118&name=i46.jpg) | I-01-10-316 | Torque Inlet Tee | | ![i47](https://www.irriline.com/hs-fs/hubfs/i47.jpg?width=190&height=118&name=i47.jpg) | I-01-10-078 | ½” Cast Iron Tee | | ![i48](https://www.irriline.com/hs-fs/hubfs/i48.jpg?width=190&height=118&name=i48.jpg) | I-01-20-078 | Valve Opening Elbow | | ![i57](https://www.irriline.com/hs-fs/hubfs/i57.jpg?width=190&height=118&name=i57.jpg) | I-01-20-552 | Sprinkler Leveler | | ![i58](https://www.irriline.com/hs-fs/hubfs/i58.jpg?width=190&height=118&name=i58.jpg) | I-01-20-552/1 | ¾” Galvanized Elbow | | ![i59](https://www.irriline.com/hs-fs/hubfs/i59.jpg?width=201&height=129&name=i59.jpg) | I-01-20-2505/1 | Torque Coupler Gasket | | ![i60](https://www.irriline.com/hs-fs/hubfs/i60.jpg?width=190&height=118&name=i60.jpg) | I-01-20-552/2 | Galvanized Pipe Riser | | ![i61](https://www.irriline.com/hs-fs/hubfs/i61.jpg?width=190&height=118&name=i61.jpg) | I-01-20-468 I-01-20-469 | Bolt for Motoroll Wheel 10 mm X 25 mm Bolt for Chassis 10 mm X 60 mm | | ![i71](https://www.irriline.com/hs-fs/hubfs/i71.jpg?width=190&height=118&name=i71.jpg) | I-01-10-335/1 | Gasket (For Slip Joint I-01-20-335/1) | | ![i62](https://www.irriline.com/hs-fs/hubfs/i62.jpg?width=190&height=118&name=i62.jpg) | I-01-20-484 I-01-20-485 | Motoroll Nut 10 mm Motoroll Nut 12 mm | | ![i63](https://www.irriline.com/hs-fs/hubfs/i63.jpg?width=190&height=118&name=i63.jpg) | I-01-20-470 | Motoroll Bolt & Nut 12 mm X 120 | | ![i64](https://www.irriline.com/hs-fs/hubfs/i64.jpg?width=190&height=118&name=i64.jpg) | I-01-10-031 | Oil Fill Cap | ## Frequently Asked Questions ##### What is a hand roll irrigation system? A hand roll is a wheeled aluminum sprinkler line that is moved by hand instead of by engine. One worker turns a double wheel fixed at the centre of the line to roll it to the next position. There is no power unit to buy, fuel or maintain. ##### What lengths are available? From 72 m to 192 m, built from 4-inch by 6 m extruded aluminum pipes. ##### How are the sprinklers and wheels spaced? 3/4-inch full-circle brass sprinklers sit on levelers every 12 m. Hot-dip galvanized wheels are also spaced every 12 m, with a wheel at each end of the line for alignment. ##### How does a hand roll connect to the water supply? Through a 4-inch by 6 m UV-resistant flexible hose rated to 10 bar, which connects the line to a hydrant on the mainline. ##### Hand roll or side roll? A hand roll costs less up front and has no engine. A side roll handles much longer lines and needs less effort to move. If your field is under about 200 m wide and labour is available, a hand roll is often enough. ## We Have the Solutions You Need Get in touch with us today for your sprinkler and irrigation needs. Trusted by farmers since 1988. ### Contact Us [![irriline\_logo](https://www.irriline.com/hubfs/irriline_logo.png)](https://www.irriline.com) - [Home](https://www.irriline.com) - [Pricing](https://www.irriline.com/pricing) - [Blog](https://www.irriline.com/blog) - [Resources](https://www.irriline.com/resources) - [About Us](https://www.irriline.com/about-us) - [Products](https://www.irriline.com/products) - [Side Roll Irrigation Systems](https://www.irriline.com/side-roll-irrigation) - [Hand Roll Irrigation Systems](https://www.irriline.com/hand-roll-irrigation) - Sprinkler Irrigation Systems - [Aluminum Pipes and Fittings](https://www.irriline.com/aluminum-pipes-and-fittings) - Sprinklers - Plastic Sprinklers - [Plastic Sprinkler IR–36P](https://www.irriline.com/plastic-sprinkler-ir-36p) - [Plastic Sprinkler IR – JUNIOR](https://www.irriline.com/plastic-sprinkler-ir-junior) - [Plastic Sprinkler IR-36-PC](https://www.irriline.com/plastic-sprinkler-ir-36-pc) - [Plastic Sprinkler IR–38P](https://www.irriline.com/plastic-sprinkler-ir-38p) - [Plastic Sprinkler IR–22P](https://www.irriline.com/plastic-sprinkler-ir-22p) - Brass Sprinklers - [Brass Sprinkler IR–30L](https://www.irriline.com/brass-sprinkler-ir-30l) - [Brass Sprinkler IR-30 / IR-30AF](https://www.irriline.com/brass-sprinkler-ir-30-/-ir-30af) - [Brass Sprinkler IR–32](https://www.irriline.com/brass-sprinkler-ir-32) - [Brass Sprinkler IR–33](https://www.irriline.com/brass-sprinkler-ir-33) - [Brass Sprinkler IR–34](https://www.irriline.com/brass-sprinkler-ir-34) - [Brass Sprinkler IR-34-PC](https://www.irriline.com/brass-sprinkler-ir-34-pc) - [Brass Sprinkler IR-40](https://www.irriline.com/brass-sprinkler-ir-40) - [Brass Sprinkler IR–40PC](https://www.irriline.com/brass-sprinkler-ir-40pc) - [Brass Sprinkler IR-15 L](https://www.irriline.com/brass-sprinkler-ir-15-l) - [Brass Sprinkler IR-20](https://www.irriline.com/brass-sprinkler-ir-20) - [Brass Sprinkler IR–25](https://www.irriline.com/brass-sprinkler-ir-20-0) - Drip Irrigation - [Non-Pressure Compensating Dripline](https://www.irriline.com/non-pressure-compensating-dripline-irripipe-sd) - [Pressure Compensating Drip Line](https://www.irriline.com/pressure-compensating-drip-line-irripipe-pc) - [Tape with Drippers (Irrilite)](https://www.irriline.com/tape-with-drippers-irrilite) - [PC on line Dripper (Micro Flapper)](https://www.irriline.com/pc-on-line-dripper-micro-flapper) - Fittings - [Compression Fittings](https://www.irriline.com/compression-fittings) - Filtration Systems - [Polypropylene Screen Filter](https://www.irriline.com/polypropylene-screen-filter) - [Tornado Disc Filter](https://www.irriline.com/tornado-disc-filter) - Valves and Accessories - [Single Union PVC Ball Valve](https://www.irriline.com/single-union-pvc-ball-valve) - [Double Union PVC Ball Valve](https://www.irriline.com/double-union-pvc-ball-valve) - [Flange Type PVC Ball Valve](https://www.irriline.com/flange-type-pvc-ball-valve) - [Air Relief Valve](https://www.irriline.com/air-relief-valve) - [Venturi Injector With Rota-Meter](https://www.irriline.com/venturi-injector-with-rota-meter) - [Valve Box](https://www.irriline.com/valve-box) - [Brass Quick Coupling Valve](https://www.irriline.com/brass-quick-coupling-valve) - [Plastic Quick Coupling Valve](https://www.irriline.com/plastic-quick-coupling-valve) Main Headquarters [![Vector](https://www.irriline.com/hubfs/Vector.svg) +1 (604) 771 - 9931](tel:+16047719931) [![Group 4](https://www.irriline.com/hubfs/Group%204.svg) 609-1489 Marine drive west Vancouver BC V7T1B8 Canada](tel:https://maps.app.goo.gl/sF7B8NiHqY5EFLwo7) Our Dealers [Australia](https://www.irriline.com/dealers#australia) [Tunisia](https://www.irriline.com/dealers#tunisia) [UAE](https://www.irriline.com/dealers#uae) [France](https://www.irriline.com/dealers#france) [Czechia](https://www.irriline.com/dealers#czechia) © Irriline Technologies Corp. All rights reserved. ```json { "@context" : "https://schema.org", "@type" : "FAQPage", "inLanguage" : "en", "mainEntity" : [ { "@type" : "Question", "acceptedAnswer" : { "@type" : "Answer", "text" : "A hand roll is a wheeled aluminum sprinkler line that is moved by hand instead of by engine. One worker turns a double wheel fixed at the centre of the line to roll it to the next position. There is no power unit to buy, fuel or maintain." }, "name" : "What is a hand roll irrigation system?" }, { "@type" : "Question", "acceptedAnswer" : { "@type" : "Answer", "text" : "From 72 m to 192 m, built from 4-inch by 6 m extruded aluminum pipes." }, "name" : "What lengths are available?" }, { "@type" : "Question", "acceptedAnswer" : { "@type" : "Answer", "text" : "3/4-inch full-circle brass sprinklers sit on levelers every 12 m. Hot-dip galvanized wheels are also spaced every 12 m, with a wheel at each end of the line for alignment." }, "name" : "How are the sprinklers and wheels spaced?" }, { "@type" : "Question", "acceptedAnswer" : { "@type" : "Answer", "text" : "Through a 4-inch by 6 m UV-resistant flexible hose rated to 10 bar, which connects the line to a hydrant on the mainline." }, "name" : "How does a hand roll connect to the water supply?" }, { "@type" : "Question", "acceptedAnswer" : { "@type" : "Answer", "text" : "A hand roll costs less up front and has no engine. A side roll handles much longer lines and needs less effort to move. If your field is under about 200 m wide and labour is available, a hand roll is often enough." }, "name" : "Hand roll or side roll?" } ] } ```
